ADDLINK S95 2TB NVME GEN4 7400MB/S WITH DRAM CACHE

Solid-State-Drive Capacity: 2 TB (2000 GB) Variants: 1 TB 2 TB Overprovisioning: 185.4 GB / 10.0 % Production: Active Released: Dec 14th, 2020 Price at Launch: 445 USD Part Number: Addlink S95 2TB Market: Consumer Form Factor: M.2 2280 (Double-Sided) Interface: PCIe 4.0 x4 Protocol: NVMe 1.4 Controller Manufacturer: Phison Name: PS5018-E18-41 Find More Drives Architecture: ARM 32-bit Cortex-R5 Core Count: 5-Core Frequency: 1,000 MHz Foundry: TSMC Process: 12 nm Flash Channels: 8 @ 1,600 MT/s Chip Enables: 4 Controller Features: DRAM (enabled) NAND Flash Manufacturer: Micron Name: B27B FortisFlash Part Number: IA7BG64AIA Type: TLC Technology: 96-layer Speed: 533 MT/s .. 1200 MT/s Capacity: 8 chips @ 2 Tbit ONFI: 4.1 Topology: Floating Gate Process: 20 nm Dies per Chip: 4 dies @ 512 Gbit Planes per Die: 4 Decks per Die: 2 Word Lines: 108 per NAND String 88.9% Vertical Efficiency Read Time (tR): 87 µs Program Time (tProg): 800 µs Block Erase Time (tBERS): 15 ms Die Write Speed: 84 MB/s Endurance: (up to) 3000 P/E Cycles (40000 in SLC Mode) Page Size: 16 KB Block Size: 3456 Pages Plane Size: 338 Blocks DRAM Cache Type: DDR4-2666 CL19 Name: SK Hynix H5AN8G6NCJR-VKC Capacity: 2048 MB (2x 1024 MB) Organization: 8Gx16 Performance Sequential Read: 7,100 MB/s Sequential Write: 6,800 MB/s Random Read: 650,000 IOPS Random Write: 700,000 IOPS Endurance: 1400 TBW Warranty: 5 Years MTBF: 2.0 Million Hours Drive Writes Per Day (DWPD): 0.4 SLC Write Cache: approx. 206 GB (dynamic only) Speed when Cache Exhausted: approx. 1688 MB/s Cache Folding Speed: 1100 MB/s Features TRIM: Yes SMART: Yes Power Loss Protection: No Encryption: Unknown RGB Lighting: No PS5 Compatible: Yes
